Key Features:
-
Fully Automated Inline Operation: Integrates seamlessly into existing production lines for uninterrupted potting processes.
-
Accurate AB Ratio Control: Equipped with precision metering pumps to maintain stable mixing ratios and consistent dispensing.
-
High-Precision Dispensing: Ensures accurate potting volumes with repeatable results to meet strict quality standards.
-
Dynamic Mixing System: Supports both static and dynamic mixers to accommodate different types of two-component materials.
-
User-Friendly Interface: Intuitive touchscreen control panel with programmable parameters for easy setup and operation.
-
Real-Time Monitoring: Integrated sensors and alarm systems monitor flow rate, pressure, and material levels for stable operation.
-
Efficient Cleaning System: Automatic flushing and cleaning function to minimize downtime and prevent material curing in the system.
| Models | XY-SY540 |
|---|---|
| Working range | X500*Y400*Z120mm |
| Maximum load | X/Y: 20kg; Z: 8KG |
| Moving speed | X/Y: ≤ 800mm/s; Z: ≤ 300mm/s |
| Motion accuracy | ±0.01mm |
| Dispensing accuracy | ≤ ±0.03mm |
| Glue ratio | 1:1~20:1 (customizable) |
| Vision system | Optional |
| Pipeline width | 100~500mm |
| Transmission mode | Timing belt / speed doubling chain / plug-in chain (optional) |
| Incoming induction | Optical fiber / photoelectric |
| Transmission mode | Servo motor + ball screw |
| Measurement mode | Metering pump |
| Mixed mode | Dynamic mixing / static mixing (optional) |
| Glue storage mode | 2 high precision vacuum pressure barrels + 1 cleaning barrel |
| Operation mode | PC with vision; teaching pendant without vision |
| Anti-curing function | Provided |
| Input power | AC220V 50–60Hz |
| Overall dimension | Approx. W1300*L900*H1600mm (subject to actual product) |
| Weight | Approx. 1500kg |
